Shanghai Bojin Electric Power Tool Acetabulum Reaming Drill 5507B for Orthopedics Surgery Joint Trauma System 5000
The Acetabulum Reaming Drill 5507B from Shanghai Bojin Medical is engineered to meet the demanding requirements of orthopedic surgeons performing hip joint reconstruction and trauma procedures. Designed as part of the System 5500 series, this advanced surgical drill provides stable torque, smooth rotation, and exceptional precision during acetabular preparation. Whether used in total hip arthroplasty or complex joint trauma repair, the Acetabulum Reaming Drill 5507B delivers dependable performance and consistent surgical outcomes.
- Overview
- Recommended Products
- Total Hip Arthroplasty (THA) for precise acetabulum socket reaming
- Revision hip procedures requiring controlled bone removal
- Orthopedic trauma surgeries involving pelvic fractures
- Joint reconstruction where accuracy and torque consistency are critical
- Implant preparation for acetabular cups and reconstruction plates
- Reaming tasks across multiple orthopedic specialties
With the perfect shape of ergonomic design, whole unit is autoclavable,motor is imported, low noise, high torque, long service life. The machine is warranty for 2 years. Different interface can be customized according to different factory’s shaft and reamer, tool connecting is very convenient and quick,higher stability.
Applications
The Acetabulum Reaming Drill 5507B is specifically optimized for orthopedic joint and trauma surgeries where stability and torque output are essential. It is widely used in:
Its ability to maintain stable power output under heavy surgical load makes the Acetabulum Reaming Drill 5507B a reliable instrument for hospital operating rooms and orthopedic centers.
Features & Advantages
1. Powerful Motor & Stable Output
With a maximum output of 200W, the Acetabulum Reaming Drill 5507B ensures surgeons have the cutting strength needed for demanding acetabular preparation. Its 250 rpm speed is optimized to deliver smooth, controlled drilling that prevents unnecessary tissue stress.
2. High Torque for Precision Surgery
The device features a 15Nm maximum torque, delivering exceptional control during slow-speed reaming. This stability is especially important in hip reconstruction and joint trauma operations where consistency directly impacts surgical precision.
3. Brushless Motor Technology
The brushless motor reduces mechanical wear, lowers maintenance requirements, and delivers a longer service life. This ensures the Acetabulum Reaming Drill 5507B continues to perform reliably even after repeated sterilization cycles and heavy clinical use.
4. 134°C Autoclavable Design
The detachable autoclavable battery case and high-temperature-resistant structure support 134°C, 5-minute autoclaving, ensuring full compliance with operating room sterilization protocols. This enhances infection control and provides a higher standard of safety.
5. High-Strength Stainless Steel Structure
All key components are engineered from medical-grade stainless steel, offering exceptional durability, corrosion resistance, and long-term performance.
6. Ergonomic & Low-Noise Operation
The ergonomic design ensures comfortable handling, reduces fatigue during long procedures, and enhances surgical accuracy. Noise output of ≤40 dB contributes to a stable and quiet operating environment, helping surgeons maintain concentration.
Specification
Output power |
max 200w |
||||||
Speed (rpm) |
250 |
||||||
Max Torque |
15Nm |
||||||
Battery |
9.6V, 1800mA |
||||||
Autoclavable |
134°C, 5min |
||||||
Noise(db) |
≤40 |
||||||
Why Choose Bojin Power Tool System 5500
The Acetabulum Reaming Drill 5507B is developed by Shanghai Bojin Medical, a global manufacturer with more than 30 years of experience in orthopedic surgical systems. Bojin’s commitment to innovation, safety, and clinical performance is reflected in every detail of the System 5500 series.
- Reasons hospitals and surgeons choose this system include:
- Over 30 years of orthopedic device manufacturing expertise
- International certifications: CCC, ISO9001, ISO13485, CE, and U.S. FDA registration
- A strong R&D team representing over 20% of total staff
- Industry-leading partnerships with medical universities and clinical experts
- Proven reliability across orthopedic departments worldwide
With its advanced design and strict quality standards, the Acetabulum Reaming Drill 5507B offers a superior balance of precision, safety, and durability.
Conclusion
The Acetabulum Reaming Drill 5507B is a high-performance orthopedic surgical tool designed for precision, reliability, and long-term durability. With strong torque output, optimized speed, a brushless motor, and full autoclavable capability, it provides surgeons with the stability and confidence required during complex hip and trauma procedures. Supported by the engineering excellence of Bojin Medical and the trusted performance of the System 5500 series, the Acetabulum Reaming Drill 5507B stands as a dependable solution for hospitals, orthopedic surgeons, and trauma specialists worldwide.
Bojin provides customized services to customers,including but not limited to drill bits, saw blades , burs and sterilization case.
It should be noted that customized products usually require an order minimum quantity and a longer waiting time than regular products.
For specific information, please contact the corresponding sales representative.
Warranty
The handpiece is guaranteed for 2 years.
The battery and other fast-consumption items are guaranteed for 3 months.
Assistance and Repair
If you need technical assistance regarding the use or application of this product, or if you encounter a problem that requires servicing or repair, contact your Bojin Sales Representative. Outside the P.R.C., contact your local Bojin Representative or your local Bojin Service Center.
Products returned for repair must have an authorized Service Request (S.R.) number prominently displayed on the box and included on all paperwork. Refer to this number if making inquiries about the repair status. Please call Bojin Customer Service and provide the following information to obtain an S.R. number prior to returning any product for repair:
- Product Number
- Serial/Lot Number
- Reason for Return
- Original Invoice Number
- Date of Purchase
- Detailed Description of the Problem
